Grade 80 Alloy Bolt Type Chain Dee Shackle

Description

Grade 80 Alloy Bolt Type Chain Dee Shackle-China LG™

China LG™ introduces the Grade 80 Alloy Bolt Type Chain Dee Shackle, a high-quality hardware component designed for various applications.
China LG™ proudly presents the Grade 80 Alloy Bolt Type Chain Dee Shackle, also known as the Grade 80 safety pin D shackle, a versatile and reliable hardware solution for a wide range of applications. This shackle is designed to provide superior protection for lifting slings, guarding against damage caused by cutting or abrasion. The anchor bow style of the shackle allows it to accommodate loads or pulls from multiple angles, making it a versatile choice for various lifting tasks.
The Grade 80 Alloy Bolt Type Chain Dee Shackle is commonly used in lifting applications, offering secure connections to chains, wire ropes, and other rated fittings in industries such as marine, agricultural, mining, and engineering. Its durable construction and high-quality materials ensure reliable performance in demanding environments.
Manufactured using superior-grade raw materials in compliance with international quality standards, these shackles are built to withstand heavy loads and provide long-lasting durability. The Grade 80 Alloy Bolt Type Chain Dee Shackle from China LG™ is a trusted solution for ensuring safe and efficient lifting operations.
Available in both standard and customized sizes, our range of safety pin chain shackles can be tailored to meet your specific project requirements. Trust in the quality craftsmanship and performance of the Grade 80 Alloy Bolt Type Chain Dee Shackle from China LG™ for all your lifting and rigging needs.

Technical & Application

Grade	80
Technical Notes	U.S. Federal Specification
Safety Factor	5 : 1
Material	Super Alloy Steel
Processing	Drop Forged / Quenched and Tempered
Surface Finished	Body : Hot Dipped Galvanized Pin : Powder Coating
Size	5/16” , 3/8” , 7/16” , 1/2” , 5/8” , 3/4” , 7/8” , 1” , 1-1/8” , 1-1/4” , 1-3/8” , 1-1/2” , 1-3/4” , 2”
Tips	Special specification and marks can be made according to customers’ requirements

Specification-Grade 80 Alloy Bolt Type Chain Dee Shackle

Part No.	Size	Wight/LBS	WLL/T	B.L/T	A±1.5	D±1	N	L±3	L1±3	B
LG-8-CS+B-5/16	5/16″	0.23	1.2	6	13.5	8	9.5	48.5	50.5	8.4
LG-8-CS+B-3/8	3/8″	0.33	1.6	8	16.8	9.7	11	58.4	62	10.8
LG-8-CS+B-7/16	7/16″	0.49	2.5	12.5	19	11.2	13	67.6	70	12.8
LG-8-CS+B-1/2	1/2″	0.75	3.3	16.5	20.6	12.7	16	77	79.9	14.8
LG-8-CS+B-5/8	5/8″	1.47	5	25	27	17.5	19	97.3	1101.5	18
LG-8-CS+B-3/4	3/4″	2.52	7	35	32	20.6	22	116.6	117.5	19.4
LG-8-CS+B-7/8	7/8″	3.85	9.5	47.5	36.6	24.6	25	135.4	136	21.5
LG-8-CS+B-1/1	1″	5.55	12.5	62.5	43	27	28	152.4	153.5	23.8
LG-8-CS+B-1-1/8	1-1/8″	7.6	15	75	46	31.8	32	172.4	171.5	25.6
LG-8-CS+B-1-1/4	1-1/4″	10.81	18	90	51.6	35	35	190.5	192	31
LG-8-CS+B-1-3/8	1-3/8″	13.75	21	105	57	35	38	206.8	202	33.4
LG-8-CS+B-1-1/2	1-1/2″	18.5	30	150	60.5	41	42	230.1	222	34
LG-8-CS+B-1-3/4	1-3/4″	31.4	40	200	73.2	53.8	51	279	278	38
LG-8-CS+B-2/1	2″	46.75	55	275	82.5	61	57	324.6	307	45
