Grade 80 Alloy Screw Pin Chain Dee Shackle

Description

Grade 80 Alloy Screw Pin Chain Dee Shackle-China LG™

China LG™ presents the Grade 80 Alloy Screw Pin Chain Dee Shackle, a premium hardware component designed for various applications.
China LG™ proudly introduces the Grade 80 Alloy Screw Pin Chain Dee Shackle, a top-of-the-line hardware solution that combines strength, durability, and versatility for a wide range of applications. This premium shackle is expertly crafted to meet the highest standards of quality and performance, making it a reliable choice for demanding industrial, construction, and rigging tasks.
Constructed from Grade 80 alloy steel, this screw pin chain dee shackle offers exceptional strength and durability, ensuring reliable performance even in the most challenging environments. The Grade 80 alloy steel material is known for its high tensile strength and resistance to wear and tear, making it ideal for heavy-duty lifting, rigging, and anchoring applications.
The screw pin design of the shackle allows for easy and secure attachment, providing a quick and reliable connection point for chains, ropes, cables, and other hardware. With its chain dee configuration, this shackle is versatile and can be used for a wide range of lifting and rigging applications, providing a secure anchor point for various loads.
Whether you need a dependable hardware component for lifting, towing, rigging, or securing heavy loads, the Grade 80 Alloy Screw Pin Chain Dee Shackle from China LG™ is the perfect choice. Trust in the quality craftsmanship and performance of this premium shackle to meet your specific project requirements with ease and reliability.
China LG™ proudly presents the Grade 80 Alloy Screw Pin Chain Dee Shackle, also known as a D-shackle for its distinctive “D” shape, a versatile hardware component designed to meet a variety of rigging and lifting needs. The straight legs of the screw pin chain shackle make it an ideal choice for applications that involve two-directional pulls, providing stability and security in demanding environments.
While screw pin chain shackles excel in applications requiring two-directional pulls, it’s important to consider the potential stress on the sides of the shackle during multiple load direction pulls. In such cases, a bow or anchor shackle, with their rounded shape, may be a more suitable choice to minimize the risk of failure and ensure safe operation.
With a range of sizes available, including 5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1-1/4”, 1-3/8”, 1-1/2”, 1-3/4”, and 2”, you can select the appropriate Grade 80 Alloy Screw Pin Chain Dee Shackle to match your specific project requirements. Whether you need a reliable shackle for lifting heavy loads, securing equipment, or rigging applications, China LG™ provides a comprehensive range of sizes to ensure you have the right hardware for the job. Trust in the durability and performance of the Grade 80 Alloy Screw Pin Chain Dee Shackle for all your rigging and lifting needs.


Technical & Application

Grade	80
Technical Notes	U.S. Federal Specification
Safety Factor	5 : 1
Material	Super Alloy Steel
Processing	Drop Forged / Quenched and Tempered
Surface Finished	Body : Hot Dipped Galvanized Pin : Powder Coating
Size	5/16” , 3/8” , 7/16” , 1/2” , 5/8” , 3/4” , 7/8”1” , 1-1/8” , 1-1/4” , 1-3/8” , 1-1/2” , 1-3/4” , 2”
Tips	Special specification and marks can be made according to customers’ requirements

Specification-Grade 80 Alloy Screw Pin Chain Dee Shackle

Part No.	Size	Weight/LBS	WLL/T	B.L/T	A±1.5	D±1	L±3	N
LG-8-CS+S-5/16	5/16″	0.17	1.2	6	13.5	8	48.5	9.5
LG-8-CS+S-3/8	3/8″	0.28	1.6	8	16.8	9.7	58.4	11
LG-8-CS+S-7/16	7/16″	0.43	2.5	12.5	19	11.2	67.6	13
LG-8-CS+S-1/2	1/2′	0.59	3.3	16.5	20.6	12.7	77	16
LG-8-CS+S-5/8	5/8″	1.25	5	25	27	17.5	97.3	19
LG-8-CS+S-3/4	3/4″	2.63	7	35	32	20.6	116.6	22
LG-8-CS+S-7/8	7/8″	3.16	9.5	47.5	36.6	24.6	135.4	25
LG-8-CS+S-1/1	1″	4.75	12.5	62.5	43	27	152.4	28
LG-8-CS+S-1-1/8	1-1/8″	6.75	15	75	46	31.8	172.4	32
LG-8-CS+S-1-1/4	1-1/4″	9.06	18	90	51.6	35	190.5	35
LG-8-CS+S-1-3/8	1-3/8″	11.63	21	105	57	35	206.8	38
LG-8-CS+S-1-1/2	1-1/2″	15.95	30	150	60.5	41	230.1	42
LG-8-CS+S-1-3/4	1/3/4″	26.75	40	200	73.2	53.8	279	51
LG-8-CS+S-2/1	2″	42.31	55	275	82.5	61	324.6	57
